Get Ready to Measure with the PosiTector 6000

The PosiTector 6000 is a Coating Thickness Gage for All Metal Substrates

What is the PosiTector 6000?

The PosiTector 6000 is an advanced coating inspection tool used to measure a wide range of important characteristics. It’s capable of testing for everything from profile depth and dry film thickness to adhesion strength, humidity levels and more. This comprehensive device also features ultrasonic measurement technology that allows users to identify areas where rust or other forms of corrosion may have impacted the substrate beneath the coating. On top of that, it can detect small flaws in even the toughest coatings thanks to its high-resolution imaging capabilities. In short, the PosiTector 6000 is an invaluable tool when it comes to accurately assessing the condition of complex surfaces.

PosiTector 6000 Gage Benefits

Rugged and Fully Electronic

The PosiTector 6000 is a rugged and fully electronic coating thickness gage that can be used on both ferrous and non-ferrous metals. With its magnetic and eddy current principles, this gage allows for accurate and fast measurements of paint thickness. No calibration adjustment is required for most applications!

Weatherproof, Dustproof, and Water-Resistant

The PosiTector 6000 is designed to excel in even the toughest of conditions. Its IP65-rated enclosure makes it weatherproof, dustproof, and water-resistant, so you can be sure it will last through any job. The wear resistant ruby probe tip also ensures calibration accuracy for a long time.

Connectivity Options

The PosiTector 6000 also features USB, WiFi, and Bluetooth connectivity to PosiSoft PC, Mac, and Smartphone software. Plus, when you purchase one of our gages, you will receive a Certificate of Calibration showing traceability to NIST or PTB (Long Form). So you can be sure that your gage is accurate and reliable.

PosiTector UTG M Probe Model
PosiTector UTG M Probe Model
Key Features



1. The PosiTector 6000 Paint Thickness Gage or Gauge is a fully electronic device that uses magnetic and eddy current principles to measure paint thickness on both ferrous and non-ferrous metals accurately and quickly without calibration adjustment for most applications.

2. The gage features a larger 2.8″ impact-resistant color touchscreen with redesigned keypad for quick navigation, as well as an IP65-rated weatherproof, dustproof, and water-resistant enclosure for tough working conditions.

3. It also has an interchangeable platform that allows any PosiTector probe to be attached to the same gage body, plus USB, Wi-Fi, and Bluetooth connectivity to PosiSoft PC, Mac, and Smartphone software.

Simple

  • Fast measurement speed—60+ readings per minute. Enhanced FAST mode—90+ readings per minute for quick inspection.
  • Ready to measure—no adjustment required for most applications
  • NEW Larger 2.8″ impact resistant color touchscreen with redesigned keypad for quick menu navigation
  • NEW On-gage help explains menu items at the touch of a button
  • Flashing display—ideal in a noisy environment
  • RESET feature instantly restores factory settings


Accurate

  • Certificate of Calibration showing traceability to NIST or PTB included
  • Built-in temperature compensation ensures measurement accuracy
  • Hi-RES mode increases displayed resolution for precision applications
  • Conforms to national and international standards including ISO and ASTM


Powerful

  • Statistics mode continually displays/updates average, standard deviation, min/max and number of readings while measuring
  • NEW Screen Capture—save 100 screen images for record keeping and review
  • HiLo alarm audibly and visibly alerts when measurements exceed user-specified limits
  • NEW Instant-on feature quickly powers up the gage if recently powered down
  • NEW Up to 30% longer battery life
  • USB port for fast, simple connection to a PC and to supply continuous power. USB cable included.
  • Every stored measurement is date and time stamped
  • Software Updates via web keep your gage current
  • Software Solutions for viewing, analyzing & reporting data

Versatile

  • PosiTector body accepts all PosiTector 6000200RTRSPGDPMIRTSSTUTGSHDBHI, and GLS probes easily converting from a coating thickness gage to a surface profile gage, dew point meter, soluble salt tester, ultrasonic wall thickness gage, hardness tester, or gloss meter
  • Multiple Calibration adjustment options including 1 point, 2 point, and ISO 19840 correction factors
  • Selectable display languages
  • NEW Auto rotating display with Flip Lock
  • Extended cables available (up to 75 m/250 ft) for underwater or remote measuring
  • Mils/Microns/mm switchable



Durable

  • NEW Weatherproof, dustproof, and water-resistant—IP65-rated enclosure
  • NEW Ergonomic design with durable rubberized grip
  • Wear-resistant probe tip
  • Shock-absorbing, protective rubber holster for added impact resistance
  • Two year warranty on gage body AND probe





Standard Models

Includes ALL features as shown plus…
  • NEW Storage of 1,000 readings per probe—stored readings can be viewed or downloaded



Advanced Models

Includes ALL features as shown plus…
  • NEW Storage of 250,000 readings in up to 1,000 batches and sub-batches
  • Live graphing of measurement data
  • NEW Prompted Batch Mode—create pre-defined batches with on-screen text and image prompts for each reading
  • 3 Scan Modes — increase measurement speed to 180+ readings per minute
  • Normal – take continuous readings without lifting the probe
  • Statistics – take continuous readings and record average, standard deviation, min/max thickness and number of readings while scanning
  • Limited Count Average – take continuous readings up to a user-specified count. The gage displays and records the average of the readings.
  • NEW Touchscreen keyboard for quickly renaming batches, adding notes, and more
  • Multiple stored calibration adjustments for measuring on a variety of substrate conditions
  • NEW Calibration Adjustment Reporting feature documents calibration adjustments into PosiSoft software reports
  • NEW SSPC-PA 2, ISO 19840, and IMO PSPC 90/10 modes help users comply with standards by prompting for min/max specifications, displaying the necessary readings, and automatically calculating statistics with a pass/fail result
  • WiFi technology wirelessly synchronizes with PosiSoft.net and downloads software updates
  • Bluetooth 4.0 Technology for data transfer to a mobile device running the PosiTector App or optional portable printer. BLE API available for integration into third-party software
  • Integrate with third-party software, drones, ROVs, PLCs, and robotic devices using several industry-standard communication protocols
  • NEW Connect a Bluetooth barcode scanner or keyboard to instantly annotate readings and batches

Shop the entire PosiTector 6000 line

If you’re looking for a rugged, reliable, versatile, and accurate coating thickness gage, the PosiTector 6000 is a perfect choice.
